Apsaras G5
3.2 m eight-head industrial transfer printer
Apsaras G5

Core Features

  • 8 Epson i3200-A1 heads  – staggered head array delivers unmatched productivity up to 363 m²/h.
  • Eco-certified sublimation inks  – GS High Density inks, OEKO-TEX approved for safe textile applications.
  • Ultra-high-speed output – powerful 1.95m format for banners, soft signage, and large textile runs.
  • Industrial media handling system – heavy-duty feeding supports stretchable fabrics and jumbo rolls with stability.
  • Grooving anti-wrinkle platen – prevents creasing and ensures smooth transfer for consistent results.
  • Intelligent IR drying system – sectional control guarantees even curing and reliable high-volume production.

Apsaras G5

Core Features

8 Epson i3200 heads
363 m²/h print speed
1.95m wide format
Industrial media handling
Anti-wrinkle platen
Sectional IR dryer

Apsaras G5

Specifications

GW.N.W:

705kgs / 906kgs

Print Head:

Eight Epson i3200-A1 Print Heads

Curing System:

This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.

Ink:

GS High Density Sublimation Transfer ink OEKO TEX Certified

Ink Supply System:

Bulk Ink Supply System With Ink Cartridge

Media Thickness:

This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.

Media Type:

Transfer Paper

Printing Size:

This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.

Data Interface:

External: Ethernet

Internal:  Fiber Optical

Working Environment:

Temp:         18℃ - 30℃

Humidity:  35% - 65%

Software:

neoStampa 10 / Ergo17 + GZ Printer Manager

Power Requirements:

Single Phase, 50Hz/AC, 220V±10%, Printer: 5.5A+IR Dryer: 18A +28A

Power Consumption:

This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.

Installed / Packed Dimensions:

LxWxH(mm): 3600×1280×1790 / 2880×1090×750

Printing Speed:

Mode            Resolution          Output


Draft             720×600 dpi      95㎡/h


Production   720×600 dpi      85㎡/h


High-res       720×1200 dpi    47㎡/h


Photo           720×1200 dpi    37㎡/h
