3 or 4 Epson i3200-U1 print heads
- the DQ1800UV runs a compact 3-head colour configuration or steps up to 4 heads to add white or varnish. It’s designed for mixed-use shops that need UV flatbed and roll-to-roll capability without buying two separate machines.
Mesh belt conveyor system
- the mesh belt design suits materials with tension - roll media, backlit films, and fabrics that would curl or buckle on a vacuum platen. It handles rigid flat sheets too, so you can run boards and rolls back-to-back on the same shift.
Multi-layer printing (up to 5 layers)
- despite the compact configuration, the DQ1800UV supports the full multi-layer stack: 2-layer (W+C), 3-layer CWC, 4-layer CKWC day-and-night, and 5-layer CWKWC for fine detail effects. Most hybrid belt printers at this price point can’t do 5-layer.
White ink recirculation (3 zones)
- three-zone white ink circulation keeps pigment in suspension across the full head array during idle time, preventing the sedimentation issues that cause blockages and uneven white opacity.
Intelligent heating unit
- active heating for both the ink supply system and the print heads maintains consistent ink viscosity and flow rate, especially important in cooler workshop environments.
Anti-collision unit
- protects the print heads if media lifts or misfeeds, preventing costly head damage during production runs.
